New vintage mini projects: '71 Bombardier + '71 Fox

[typeone]

parts have been rolling in, haven't had much time to fiddle but been doing some mockups here and there.

- i really liked the finish on the ProTaper XR50 BMX bars but the center mount point combined with pitbike clamps isn't working out. i need the clamps closer together or they're too crooked. will have to keep trying but might need to go with different parts.

- mini Sportster tank looks rad, i love it. think i have a mount plan.

- brown cafe racer seat looks sweet as well, love how the stitching lines up with the frame down tubes. i'll prob chop this much smaller than the mockups below. i kinda dig the super flat, no seat look so minimal will prob be best.

few pics, Photochop of seat and tank union



tank on seatpan, you can see the rear tab i'll inset into the pan. i'm thinking horizontal line of pan > tank, but have tried angled to match motor as well.



brown diamond grips to match the seat cover.



ordering the header and UNI filter adapter today.

[OreoGaborio]

Dammit... I hate that my company laptop blocks so many image hosting sites!

EDIT: ooooh, there we go. Thanks, Tappatalk, you useless frikkin app That looks awesome.

[backinthesaddle]

Cousin had a Fox Sundowner. Maybe called that as it had lights on it. KMart sold them. Seemed like a higher end version of the lawn mower engined, lawn chair tubing framed bikes.

[typeone]

Cousin had a Fox Sundowner. Maybe called that as it had lights on it.

sweet! wish i kept my '73 Lil Indian, thing was mint. i drove all the way to PA to grab it ... speaking of lights, bought one for this project and have a cool idea to wire up LED headlight and taillight to a rechargeable battery pack. would be fantastic for those late night rides back home after swillin' with the hood'lums.

[Gixxer]

I miss the old thread title

[typeone]

small update, been fiddling with the bar mounts and BMX bars, not working out so well. not only are the angles wrong since the bars are more narrow at the mount point, but the clamps would require me to push the tank back a little further than i'd like. the turn radius on the bike is ridiculous so the clamps would constantly be smashing into the tank.

ended up ordering a billet top clamp for an early Honda ATC70, will have to chop it to fit the Fox triple, but i'm hoping i can get it to work. bars would mount forward so no interference with tank and the billet clamp is made for BMX bars so it has proper spacing.


- - - Updated - - -

I miss the old thread title

[loudbeard]

Seemed like an appropriate place for this

[typeone]

i've had zero time for these projects but i threw the bars from The Champ and a temp tank on the Fox last night and took 'er for a rip. without a seat it rattles your teeth! hahaa. pipe came loose and rotated so that the muffler was pointed right at the steel seat pan. H O T !

mad fun.

[typeone]

messed around with the Fox over the weekend. tightened a ton of loose bolts, set chain tension, gave it a bath, degreased motor, fresh oil and fill cap, new rear shocks. ripped two nice laps of the hood then the torque converted decided to lock up. the vintage cover has been repaired with fiberglass a bunch of times and sorta permanently fixed, which sucks. i have to cut a bolt to get the cover off and inspect what the issue is.

motor runs flawlessly but it's a paint shaker. intake came loose and almost fell off. hahaa. every ride is an experience, the road rash is gonna HURT.

threw the old seat on temporarily to not get burned again.
